Mô hình | Lưu Lượng | Đẩy Cao (m) | Tốc độ (r / phút) | Công Suất Động Cơ | |
m3 / h | KW | Mô hình | |||
20-20-100 | 1 m3 / h | 20 (m) | 2800 | 0,75 | Y80M1-2 |
20-20-125 | 1,5 m3 / h | 22 (m) | 0,75 | Y80M1-2 | |
25-25-160 | 3 m3 / h | 27 (m) | 2900 | 1,5 | Y90S-2 |
32-32-160 | 6 m3 / h | 28 (m) | 1,5 | Y90S-2 | |
40-25-160 | 10 m3 / h | 28 (m) | 2.2 | Y90L-2 | |
50-32-160 | 12,5 m3 / h | 30 (m) | 3 | Y100L-2 | |
50-32-200 | 18 m3 / h | 40 (m) | 5,5 | Y132S1-2 | |
50-32-200A | 16 m3 / h | 32 (m) | 4 | Y112M-2 | |
50-32-250 | 12,5 m3 / h | 80 (m) | 11 | Y160M1-2 | |
50-32-250A | 10 m3 / h | 50 (m) | 7,5 | Y132S2-2 | |
65-50-160 | 20 m3 / h | 32 (m) | 5,5 | Y132S1-2 | |
65-40-200 | 30 m3 / h | 48 (m) | 7,5 | Y132S2-2 | |
65-40-200A | 25 m3 / h | 35 (m) | 5,5 | Y132S1-2 | |
65-40-250 | 25 m3 / h | 80 (m) | 15 | Y160M2-2 | |
65-40-250A | 20 m3 / h | 51 (m) | 7,5 | Y132S2-2 | |
65-40-315 | 25 m3 / h | 125 (m) | 30 | Y200L1-2 | |
80-50-200 | 50 m3 / h | 50 (m) | 15 | Y160M2-2 | |
80-50-200A | 45 m3 / h | 40 (m) | 11 | Y160M1-2 | |
80-50-200B | 40 m3 / h | 32 (m) | 7,5 | Y132S2-2 | |
80-50-250 | 50 m3 / h | 80 (m) | 22 | Y180M-2 | |
80-50-250A | 43 m3 / h | 60 (m) | 18,5 | Y160L-2 | |
80-50-315 | 50 m3 / h | 125 (m) | 37 | Y225L2-2 | |
80-50-315A | 45 m3 / h | 100 (m) | 30 | Y200L1-2 | |
100-65-200 | 100 m3 / h | 50 (m) | 22 | Y180M-2 | |
100-65-200A | 94 m3 / h | 44 (m) | 22 | Y180M-2 | |
100-65-250 | 100 m3 / h | 80 (m) | 37 | Y200L2-2 | |
100-65-250A | 95 m3 / h | 72 (m) | 37 | Y200L2-2 | |
100-65-315 | 100 m3 / h | 125 (m) | 75 | Y280S-2 | |
100-65-315A | 95 m3 / h | 113 (m) | 55 | Y250M-2 | |
125-100-200 | 200 m3 / h | 50 (m) | 45 | Y225M-2 | |
125-100-200A | 178 m3 / h | 40 (m) | 37 | Y200L2-2 | |
125-100-250 | 200 m3 / h | 70 (m) | 55 | Y250M-2 | |
125-100-250A | 190 m3 / h | 62 (m) | 55 | Y250M-2 | |
150-150-200 | 350 m3 / h | 50 (m) | 75 | Y280S-2 |
